This map shows modeled outdoor noise across Franklin Heights at 100-meter resolution, combining road, aviation, and rail sources. Green areas measure below 45 dBA. Orange and red exceed the EPA's 55 dBA outdoor threshold linked to long-term health effects. Use the layer toggles to view each source on its own or all together.
What the numbers sound like
- 30 dBAWhisper
- 40 dBASoft rainfall
- 45 dBAQuiet suburban street at night
- 50 dBAQuiet office
- 55 dBAEPA outdoor threshold: light traffic 100 ft away
- 60 dBANormal conversation an arm's length away
- 65 dBABusy restaurant
- 70 dBAHighway traffic 50 ft away
- 80 dBACity bus interior
Population Above the EPA Outdoor Threshold
The EPA's 55 dBA outdoor reference level is a common benchmark for residential noise exposure, especially for activity interference, annoyance, and long-term community noise concerns. About 2,796 Franklin Heights residents, or 50.6%, live above that level. By land area, 48.5% of Franklin Heights is above 55 dBA.
See how noise in Franklin Heights compares to similar-sized neighborhoods.
Noise by Part of Franklin Heights
Average noise levels for Franklin Heights residents, grouped by direction from the center of Franklin Heights. The highest population-weighted average is in southeastern Franklin Heights; the lowest is in southwestern Franklin Heights, where just 14% of residents live in blocks above the EPA's 55 dBA threshold, a fifth of the share in the loudest section.
Southeastern Franklin Heights
80% of people above 55 dBA
Northern Franklin Heights
50% of people above 55 dBA
Southern Franklin Heights
58% of people above 55 dBA
Northwestern Franklin Heights
27% of people above 55 dBA
Southwestern Franklin Heights
14% of people above 55 dBA
To the human ear, noise in southeastern Franklin Heights sounds about 31% louder than in southwestern Franklin Heights, a 3.9 dBA gap. Every 10 dBA roughly doubles perceived loudness. Within any of these directions, two homes a quarter mile apart can still differ by 10 or more dBA depending on how close they sit to a major highway.
Airport Noise
General Mitchell International (MKE) sits south of Franklin Heights. The U.S. Department of Transportation models aviation noise around this airport from federal traffic data, and the model uses those federal measurements rather than synthetic predictions.
Blocks under the approach and departure paths carry combined road-plus-aviation noise, with some exceeding 65 dBA on the map's Overall layer. Blocks on the opposite side of Franklin Heights, particularly to the north, show no measurable aviation contribution. Use the Aviation toggle on the map above to isolate the airport's footprint.
How Noise Is Distributed Across Franklin Heights
The bar chart below shows the share of Franklin Heights residents in each noise band. About 40% of residents live below the EPA's 55 dBA threshold, and roughly 6% live in blocks above 60 dBA. Long-term exposure in that range is linked to elevated stress hormones and cardiovascular risk.
How Franklin Heights Compares
Franklin Heights sits at the quieter end of the spectrum. Below: how Franklin Heights's average outdoor noise and share of residents above the EPA threshold compare with Lincoln Creek, Hampton Heights, Sherman Park, and Murray Hill.
Average noise level (dBA)
Franklin Heights's 55.6 dBA pop-weighted average is at the quieter end of the spectrum. Wisconsin as a whole averages 53.0 dBA and the U.S. averages 52.0 dBA. Both are lower than Franklin Heights because most of either area is rural land away from major roads.
Share of residents above 55 dBA
About 50.6% of Franklin Heights residents live in blocks where outdoor levels exceed the EPA's 55 dBA threshold. That's in the middle of its peer group. Measured by land area instead, 48.5% of Franklin Heights's footprint sits above 55 dBA, against a Wisconsin average of 29.6% and a national average of 28.1%.
What This Means if You're Moving to Franklin Heights
- Distance from highways matters more than the neighborhood name. Two homes in the same zip code can differ by 20 dBA if one sits 100 meters from and the other 500 meters away. The model captures this at 100-meter resolution, so noise exposure changes block by block.
- Tree canopy can help reduce modeled noise exposure. Roughly 12% of Franklin Heights is under tree cover (about average for neighborhoods), and the dominant land cover is medium-intensity developed land. Both are measured from federal USDA Forest Service and USGS satellite imagery at 30-meter resolution. Streets with 60% or higher canopy show 3 to 5 dBA lower noise than comparable streets with bare ground or pavement, which is why the per-place decay rate above already accounts for it.
- Airport noise is directional. General Mitchell International's approach paths concentrate aviation noise to the south. Neighborhoods to the north of downtown show no measurable contribution from the airport.
Sources & Methodology
The BestNeighborhood noise model is calibrated against nearly one million federal ground-truth measurements across four states. Road noise is computed from segment-level federal traffic data and propagated outward using physics-based acoustic decay, with attenuation rates that depend on the surrounding land cover.
Federal datasets used:
FHWA Highway Performance Monitoring System: road geometry, traffic counts, lane configuration
U.S. DoT Bureau of Transportation Statistics National Transportation Noise Map: aviation and rail noise, road calibration ground truth
USGS / MRLC National Land Cover Database: land cover and impervious surface coverage
USDA Forest Service Tree Canopy Cover: vegetation density for sound propagation
U.S. Census Bureau TIGER/Line: block-level geography and population
U.S. EPA Levels Document: 55 dBA outdoor reference level
All inputs are published federal datasets. Block-level noise is computed by combining road, rail, and aviation sound sources in the energy domain, the same physics used in professional environmental noise assessments. Read the full methodology.
