This map shows modeled outdoor noise across Woodson Terrace at 100-meter resolution, combining road, aviation, and rail sources. Green areas measure below 45 dBA. Orange and red exceed the EPA's 55 dBA outdoor threshold linked to long-term health effects. Use the layer toggles to view each source on its own or all together.
What the numbers sound like
- 30 dBAWhisper
- 40 dBASoft rainfall
- 45 dBAQuiet suburban street at night
- 50 dBAQuiet office
- 55 dBAEPA outdoor threshold: light traffic 100 ft away
- 60 dBANormal conversation an arm's length away
- 65 dBABusy restaurant
- 70 dBAHighway traffic 50 ft away
- 80 dBACity bus interior
Population Above the EPA Outdoor Threshold
The EPA's 55 dBA outdoor reference level is a common benchmark for residential noise exposure, especially for activity interference, annoyance, and long-term community noise concerns. About 2,404 Woodson Terrace residents, or 72.7%, live above that level. By land area, 79.6% of Woodson Terrace is above 55 dBA.
See how noise in Woodson Terrace compares to similar-sized cities.
Noise by Part of Woodson Terrace
Average noise levels for Woodson Terrace residents, grouped by direction from the center of Woodson Terrace. Northern Woodson Terrace carries the highest population-weighted average; Western Woodson Terrace carries the lowest. Just 52% of residents in Western Woodson Terrace live in blocks above the EPA's 55 dBA threshold, about two-thirds of the share in Northern Woodson Terrace.
Central Woodson Terrace
73% of people above 55 dBA
Eastern Woodson Terrace
92% of people above 55 dBA
Northern Woodson Terrace
100% of people above 55 dBA
Southern Woodson Terrace
79% of people above 55 dBA
Western Woodson Terrace
52% of people above 55 dBA
Northern Woodson Terrace sounds about 21% louder than Western Woodson Terrace to the human ear, a 2.7 dBA gap. Every 10 dBA roughly doubles perceived loudness. Within any of these directions, two homes a quarter mile apart can still differ by 10 or more dBA depending on how close they sit to a major highway.
Loudest Road Corridors
The model evaluates every road in Woodson Terrace using federal traffic counts, posted speeds, heavy-truck ratios, and pavement type. The source level shown is the modeled noise at the road centerline, where it is loudest. Noise drops with distance, faster in vegetated areas and slower over open pavement.
How far back from I-70 do you need to be?
I-70 produces an estimated 78 dBA at its loudest centerline points. Noise drops logarithmically with distance, with the exact rate depending on what's between you and the road. Tree cover, walls, terrain, and pavement type all matter. At roughly a quarter mile back, traffic fades into the noise level of a quiet suburban street at night.
Calculated from the model's calibrated attenuation formula. About 26% of Woodson Terrace sits under tree canopy (about average for cities) and roughly 40% is impervious surface like pavement and rooftops. Both are folded into the per-place decay rate above. Heavier canopy pulls noise down faster with distance; impervious surfaces slow the drop.
Airport Noise
St Louis Lambert International (STL) sits north of Woodson Terrace. The U.S. Department of Transportation models aviation noise around this airport from federal traffic data, and the model uses those federal measurements rather than synthetic predictions.
Blocks under the approach and departure paths carry combined road-plus-aviation noise, with some exceeding 60 dBA on the map's Overall layer. Blocks on the opposite side of Woodson Terrace, particularly to the south, show no measurable aviation contribution. Use the Aviation toggle on the map above to isolate the airport's footprint.
How Noise Is Distributed Across Woodson Terrace
The bar chart below shows the share of Woodson Terrace residents in each noise band. About 12% of residents live below the EPA's 55 dBA threshold, and roughly 19% live in blocks above 60 dBA. Long-term exposure in that range is linked to elevated stress hormones and cardiovascular risk.
How Woodson Terrace Compares
Woodson Terrace sits at the quieter end of the spectrum. Below: how Woodson Terrace's average outdoor noise and share of residents above the EPA threshold compare with Normandy, Northwoods, Breckenridge Hills, and Bel-Ridge.
Average noise level (dBA)
Woodson Terrace's 58.4 dBA pop-weighted average is at the quieter end of the spectrum. Missouri as a whole averages 53.9 dBA and the U.S. averages 52.0 dBA. Both are lower than Woodson Terrace because most of either area is rural land away from major roads.
Share of residents above 55 dBA
About 72.7% of Woodson Terrace residents live in blocks where outdoor levels exceed the EPA's 55 dBA threshold. That's in the middle of its peer group. Measured by land area instead, 79.6% of Woodson Terrace's footprint sits above 55 dBA, against a Missouri average of 32.5% and a national average of 28.1%.
What This Means if You're Moving to Woodson Terrace
- Distance from highways matters more than the neighborhood name. Two homes in the same zip code can differ by 20 dBA if one sits 100 meters from I-70 and the other 500 meters away. The model captures this at 100-meter resolution, so noise exposure changes block by block.
- Tree canopy can help reduce modeled noise exposure. Roughly 26% of Woodson Terrace is under tree cover (about average for cities), and the dominant land cover is low-intensity developed land. Both are measured from federal USDA Forest Service and USGS satellite imagery at 30-meter resolution. Streets with 60% or higher canopy show 3 to 5 dBA lower noise than comparable streets with bare ground or pavement, which is why the per-place decay rate above already accounts for it.
- Airport noise is directional. St Louis Lambert International's approach paths concentrate aviation noise to the north. Neighborhoods to the south of downtown show no measurable contribution from the airport.
Sources & Methodology
The BestNeighborhood noise model is calibrated against nearly one million federal ground-truth measurements across four states. Road noise is computed from segment-level federal traffic data and propagated outward using physics-based acoustic decay, with attenuation rates that depend on the surrounding land cover.
Federal datasets used:
FHWA Highway Performance Monitoring System: road geometry, traffic counts, lane configuration
U.S. DoT Bureau of Transportation Statistics National Transportation Noise Map: aviation and rail noise, road calibration ground truth
USGS / MRLC National Land Cover Database: land cover and impervious surface coverage
USDA Forest Service Tree Canopy Cover: vegetation density for sound propagation
U.S. Census Bureau TIGER/Line: block-level geography and population
U.S. EPA Levels Document: 55 dBA outdoor reference level
All inputs are published federal datasets. Block-level noise is computed by combining road, rail, and aviation sound sources in the energy domain, the same physics used in professional environmental noise assessments. Read the full methodology.
